Product Detail

No. Parte: #SHD1331A-R


SKU: #SHD1331A-R

Description Value
FMSI Number1331A
Friction Material CompositionHybrid LowMet
Brake Shoe Length(mm)400
Bolt Hole Quantity10
Pad Contact Surface Width(mm)130
New Or RemanufacturedNew
Meets or Exceeds Original Equipment Manufacture SpecificationsMeets
Grade TypeRegular
Drum Diameter(in)400X130
Brake Shoe Length(in)15.75
Pad Contact Surface Width(in)5.12
Drum Diameter(mm)15.75X5.12




Also Fits

Year BRAND Model Submodel Engine (L)
1986 Isuzu NPR Base 3.9 L - 4 4BD1 U/K U/K
1987 Isuzu NPR Base 3.9 L - 4 4BD1 U/K U/K
1988 Isuzu NPR Base 3.9 L - 4 4BD1 U/K U/K
1989 Isuzu NPR Base 3.9 L - 4 4BD1 U/K U/K
1990 Isuzu NPR Base 3.9 L - 4 4BD1 U/K U/K
1991 Isuzu NPR Base 3.9 L - 4 4BD1 U/K U/K
1992 Isuzu NPR Base 3.9 L - 4 4BD2 U/K U/K
1992 Isuzu NPR Base 5.7 V 5733 8 - U/K U/K
1993 Hino FE2618 Base 6.5 L 6485 6 H06C-TP U/K 12
1993 Hino FF3020 Base 6.5 L 6485 6 H06C-TN U/K 12
1993 Isuzu NPR Base 3.9 L - 4 4BD2 U/K U/K
1993 Isuzu NPR Base 5.7 V 5733 8 - U/K U/K
1994 Hino FE2618 Base 6.5 L 6485 6 H06C-TP U/K 12
1994 Hino FF3020 Base 6.5 L 6485 6 H06C-TN U/K 12
1994 Isuzu NPR Base 3.9 L - 4 4BD2 U/K U/K
1994 Isuzu NPR Base 5.7 V 5733 8 - U/K U/K
1995 Hino FE2618 Base 6.5 L 6485 6 H06C-TT U/K 12
1995 Hino FF3020 Base 6.5 L 6485 6 H06C-TU U/K 12
1995 Isuzu NPR Base 3.9 L - 4 4BD2 U/K U/K
1995 Isuzu NPR Base 5.7 V 5733 8 - U/K U/K
1996 Hino FE2618 Base 6.5 L 6485 6 H06C-TT U/K 12
1996 Hino FF3020 Base 6.5 L 6485 6 H06C-TU U/K 12
1996 Isuzu NPR Base 3.9 L - 4 4BD2 U/K U/K
1996 Isuzu NPR Base 5.7 V - 8 L31 OHV 16
1997 Hino FE2618 Base 6.5 L 6485 6 H06C-TT U/K 12
1997 Hino FF3020 Base 6.5 L 6485 6 H06C-TU U/K 12
1997 Isuzu NPR Base 3.9 L - 4 4BD2 U/K U/K
1997 Isuzu NPR Base 5.7 V - 8 L31 OHV 16
1998 Hino FE2620 Base 8.0 L - 6 J08C-TD U/K U/K
1998 Hino FF3020 Base 8.0 L - 6 J08C-TD U/K U/K
1998 Isuzu NPR Base 3.9 L - 4 4BD2 U/K U/K
1998 Isuzu NPR Base 4.8 L - 4 4HE1 U/K U/K
1998 Isuzu NPR Base 5.7 V - 8 L31 OHV 16
1999 Hino FE2620 Base 8.0 L - 6 J08C-TP U/K U/K
1999 Hino FF3020 Base 8.0 L - 6 J08C-TP U/K U/K
1999 Isuzu NPR Base 4.8 L - 4 4HE1 U/K U/K
1999 Isuzu NPR Base 5.7 V - 8 L31 OHV 16
2000 Hino FE2620 Base 8.0 L - 6 J08C-TP U/K U/K
2000 Hino FF3020 Base 8.0 L - 6 J08C-TP U/K U/K
2000 Isuzu NPR Base 4.8 L - 4 4HE1 U/K U/K
2000 Isuzu NPR Base 5.7 V - 8 L31 OHV 16
2001 Hino FE2620 Base 8.0 L - 6 J08C-TP U/K U/K
2001 Hino FF3020 Base 8.0 L - 6 J08C-TP U/K U/K
2001 Isuzu NPR Base 4.8 L - 4 4HE1 U/K U/K
2001 Isuzu NPR Base 5.7 V - 8 L31 OHV 16
2002 Hino FE2620 Base 8.0 L - 6 J08C-TP U/K U/K
2002 Hino FF3020 Base 8.0 L - 6 J08C-TP U/K U/K
2002 Isuzu NPR Base 4.8 L - 4 4HE1 U/K U/K
2002 Isuzu NPR Base 5.7 V - 8 L31 OHV 16
2003 Hino FE2620 Base 8.0 L - 6 J08C-TP U/K U/K
2003 Isuzu NPR Base 4.8 L - 4 4HE1 U/K U/K
2003 Isuzu NPR Base 5.7 V - 8 L31 OHV 16
2003 Isuzu NPR Base 6.0 V 5967 8 LQ4 OHV 16
2004 Hino FE2620 Base 8.0 L - 6 J08C-TP U/K U/K
2004 Hino FF3020 Base 8.0 L - 6 J08C-TP U/K U/K
2004 Isuzu NPR Base 4.8 L - 4 4HE1 U/K U/K
2004 Isuzu NPR Base 6.0 V 5967 8 LQ4 OHV 16
2005 Isuzu NPR Base 5.2 L - 4 4HK1 U/K U/K
2005 Isuzu NPR Base 6.0 V 5967 8 LQ4 OHV 16
2006 Isuzu NPR Base 5.2 L - 4 4HK1 U/K U/K
2006 Isuzu NPR Base 6.0 V 5967 8 LQ4 OHV 16
2007 Isuzu NPR Base 5.2 L - 4 4HK1 U/K U/K
2007 Isuzu NPR Base 6.0 V 5967 8 LQ4 OHV 16
2007 Isuzu NPR Base 6.0 V 5967 8 LQ9 OHV 16
2008 Isuzu NPR Base 5.2 L - 4 4HK1 U/K U/K
2008 Isuzu NPR Base 6.0 V 5967 8 LQ4 OHV 16
2008 Isuzu NPR Base 6.0 V 5967 8 LQ9 OHV 16
2009 Isuzu NPR Base 5.2 L - 4 4HK1 U/K U/K
2009 Isuzu NPR Base 6.0 V 5967 8 LQ4 OHV 16
2009 Isuzu NPR Base 6.0 V 5967 8 LQ9 OHV 16
2010 Isuzu NPR Base 6.0 V 5967 8 LQ4 OHV 16
2010 Isuzu NPR Base 6.0 V 5967 8 LQ9 OHV 16
2011 Isuzu NPR Base 3.0 L - 4 4JJ1 U/K U/K
2011 Isuzu NPR Base 6.0 V 5967 8 LQ4 OHV 16
2011 Isuzu NPR Base 6.0 V 5967 8 LQ9 OHV 16
2012 Isuzu NPR Base 3.0 L - 4 4JJ1 U/K U/K
2012 Isuzu NPR Base 6.0 V 5967 8 L96 OHV 16
2012 Isuzu NPR Base 6.0 V 5967 8 LQ4 OHV 16
2012 Isuzu NPR Base 6.0 V 5967 8 LQ9 OHV 16
2013 Isuzu NPR Base 3.0 L - 4 4JJ1 U/K U/K
2013 Isuzu NPR Base 6.0 V 5967 8 L96 OHV 16
2014 Isuzu NPR Base 3.0 L - 4 4JJ1 U/K U/K
2014 Isuzu NPR Base 6.0 V 5967 8 L96 OHV 16
2015 Isuzu NPR Base 3.0 L - 4 4JJ1 U/K U/K
2015 Isuzu NPR Base 6.0 V 5967 8 L96 OHV 16
2016 Isuzu NPR Base 3.0 L - 4 4JJ1 U/K U/K
2016 Isuzu NPR Base 6.0 V 5967 8 L96 OHV 16
2017 Isuzu NPR Base 3.0 L - 4 4JJ1 U/K U/K
2017 Isuzu NPR Base 6.0 V 5967 8 L96 OHV 16
2018 Isuzu NPR Base 3.0 L - 4 4JJ1 U/K U/K
2018 Isuzu NPR Base 6.0 V 5967 8 L96 OHV 16
2019 Isuzu NPR Base 6.0 V 5967 8 - OHV 16
2020 Isuzu NPR Base 6.0 V 5967 8 - OHV 16
